DHS040-60-003 Ingiant USB slip ring out diameter 40mm solid solid flange design with 1 channel USB 2.0 signal
USB slip ring USB 2.0 slip ring
DHS040-60-003 USB slip ring is solid flange design, 1 channel integral structure with outer diameter 40mm USB2.0 slip ring and used to transmit USB2.0 signals. It has the advantages of stable transmission, no packet loss, no string code, small return loss, and small insertion loss.
USB slip ring can mix electrical power channels and signal channels.
- Transmit 1 USB channel at the same time.
- Integral precision conductive slip ring with all-aluminum alloy structure
- USB male connector is directly pluggable
- Precious metal + super-hard gold plating treatment
- Ultra-low BER bit error rate and ultra-high signal-to-noise ratio
Typical applications:
Machine vision, high-speed data acquisition and transmission, industrial cameras, digital television, VR, test turntables and other fields that require high-speed data transmission.
|
DHS040-60-003 |
|||
|
The main parameters |
|||
| Number of circuits | 60 | Working temperature | “-40℃~+65℃” |
| Rated current | can be customized | Working humidity | ＜70% |
| Rated voltage | 0~240 VAC/VDC | Protection level | IP54 |
| Insulation resistance | ≥1000MΩ @500VDC | Housing material | Aluminum Alloy |
| Insulation strength | 1500 VAC@50Hz,60s,2mA | Electrical contact material | Precious metal |
| Dynamic resistance variation | ＜10MΩ | Lead wire specification | Colored Teflon insulated & tinned stranded flexible wire |
| Rotating speed | 0~600rpm | Lead wire length | 500mm + 20mm |
Standard product outline drawing:
Our advantage:
1：Product advantage: Transmit analog and digital signal；Adopts gold-to-gold contact to transmit signal；Able to integrate up to 135 channels；Module design, guarantees consistency of the products；Compact structure, small size；Adopt special soft wire ；Long life, maintenance-free, easy to install, more stable performance and 360°continuous rotation to transmit power and data siganls.
2：Customized service, accurate response and technical support for customers, 12 months of the products warranty, no worry for after sales problems. With reliable products, strict qualitycontrol system, perfect pre-sale and after-sales service, Ingiant obtain strusts from more and more customers all over the world.
3：INGIANT adheres to the business philosophy of “customer-centered, quality-based, innovation-driven”, seeks to win the market with high-quality products and considerate services, in terms of pre-sales, production, after- sales and product warranty, we provide customized service to meet various demands of clients so Ingiant obtained a excellent reputation from the industry.
